Frontier MoE sleep/wake at TP=4 on consumer Blackwell — 1s wake, 3s swap

Sleep/wake rotation works fine for small dense models on a single GPU — load weights into pinned CPU RAM, swap them back to VRAM in under a second. That’s not the interesting case. The interesting case is frontier MoE at TP=4: ~17 GiB of sharded weights per GPU, sparse routing tables, KV cache across four ranks, and a co-resident peer model on the same physical cards. For months that combination on consumer Blackwell either OOM’d, hung in cuMemMap, or produced silent garbage outputs after a few rotation cycles.

It now works. Same-peer /wake_up: 1 second. Cross-peer swap (sleep model A, wake model B on the same 4 GPUs): 3 seconds. Down from 50. Live in production on 4× RTX PRO 6000 Blackwell with DeepSeek-V4-Flash and MiMo-V2.5-Flash sharing the same TP=4 pool. This is what it took — a specific image stack, two cherry-picked upstream PRs, and one non-obvious config knob.

The recipe is at github.com/DoradusResearch/vllm-blackwell-sm12x-bundle.

The setup

4× NVIDIA RTX PRO 6000 Blackwell Workstation Edition. 95 GiB per GPU. SM_120 (consumer Blackwell, no Fabric/RDMA). Goal: run a 2-model rotation pool where one is awake serving inference and the other is /sleep’d (weights copied to pinned CPU memory) so they share the same GPUs without doubling hardware.

In vLLM terms: --enable-sleep-mode with level-1 sleep. Documented use case, well-tested on H100/H200.

On consumer Blackwell, in our experience: an obstacle course.

What broke, in order

1. The b12x community image had cumem state bugs

The closest existing image is the voipmonitor b12x fork, which patches vLLM for SM_120-specific kernel paths. Excellent baseline, but on cross-peer /wake_up we got CUDA Error: invalid argument at cumem_allocator.cpp:145 reliably.

After digging it turned out this is the bug PR #35489 addresses: vLLM’s cumem allocator queries CU_DEVICE_ATTRIBUTE_HANDLE_TYPE_FABRIC_SUPPORTED to decide whether to use Fabric handles, and on hardware without Fabric (all consumer Blackwell), that query returns CUDA_ERROR_INVALID_VALUE. The error code gets cached in a global, and the next cuMemMap returns EINVAL because it sees the stale error state.

The fix is a one-line error_code = no_error; reset at the top of create_and_map. The PR has been open since March; it isn’t in any released vLLM image yet.

2. The cumem cycle leak is real but manageable

Even with #35489 applied, repeated /sleep + /wake_up cycles leak pinned GPU memory. We measured up to ~5 GiB per cycle, eventually overlapping live weight tensors and producing silent garbage outputs around cycle 4-5.

There are about 7 open vLLM issues tracking this (#36651, #21336, #34600, #37111, etc.). PR #34600 adds proper rollback in wake_up when partial allocations fail — important for not leaking on every failed wake even if it doesn’t directly fix the slow per-cycle accumulation. We cherry-pick that too.

3. The PR that fixes everything for DeepSeek-V4 also breaks the memory budget

PR #41834 is the upstream effort to land native DeepSeek-V4 support on SM12x: Triton sparse-MLA fallback, DeepGEMM-free paths, MLA prefix-cache fix. It’s the only credible path to native DSv4 without a community fork, and it makes /sleep synchronous (no more 35-second POST_SLEEP_GAP_S workaround we used to need with the jasl-on-cu130 image).

But PR #41834 also adds about ~22 GiB of GPU state per GPU that lives outside the vLLM cumem allocator’s budget — sparse-MLA workspace, marlin scratch, cuda-graph private pools. On H200 (140 GiB per GPU) this is invisible headroom. On consumer Blackwell (95 GiB) it overflows.

vLLM’s default --gpu-memory-utilization 0.85 × 95 GiB = ~80 GiB cumem budget. Plus the 22 GiB non-cumem. Plus a few GiB for any sleeping co-tenant peer. Total: ~105 GiB on a 95 GiB GPU. OOM.

4. The 22 GiB pool ignores every config knob you’d reach for

We spent a couple of days trying to shrink the 22 GiB:

• --max-cudagraph-capture-size from 12 to 4 to 1: no effect.
• cudagraph_mode: PIECEWISE only (vs FULL+PIECEWISE): no effect.
• --enforce-eager (disable cuda graphs entirely): no effect. ← the diagnostic.
• --max-num-batched-tokens 8192 → 2048: no effect.
• --max-num-seqs 12 → 4: no effect.
• --max-model-len 131072 → 32768: no effect.

The 22 GiB is hardcoded into PR #41834’s compilation framework. It’s workspace tensors and pre-allocated buffers that the user can’t tune from spec.

The misleading thing: PyTorch’s OOM message labels this “22.7 GiB allocated in private pools (e.g., CUDA Graphs)”. The “(e.g., CUDA Graphs)” sent us chasing graph-capture configuration for days. The label is technically correct but misleading — PyTorch’s “private pools” catches any tensor allocated via a torch.cuda.MemPool, including allocations done outside graph capture. The 22 GiB is workspace tensors, not graphs.

5. The actual fix is operational, not source-level

Once we understood that the 22 GiB is a hardcoded non-cumem footprint, the fix becomes obvious:

--gpu-memory-utilization 0.70   # not 0.85

0.70 × 95 GiB = 66.5 GiB cumem budget. Plus 22 GiB non-cumem. Plus 2.4-4.8 GiB sleeping peer residue. Total: ~92 GiB on a 95 GiB GPU. ~3 GiB margin. Fits.

The cost: cumem budget is smaller, so less room for weights + KV cache. DeepSeek-V4 weights at TP=4 are ~17 GiB per GPU; KV cache for max_model_len=131072 max_num_seqs=12 at FP8 is ~7 GiB. Total ~24 GiB, comfortably inside 66.5 GiB.

Measured outcome

Operation	Before (jasl-on-cu130 image)	After (this stack)
/sleep	Async, returns 200 in ~5s, actual unmap takes another 35s	Synchronous, 2-25s (returns when actually done)
/wake_up (same peer)	2s	1s
/wake_up (cross-peer, after /sleep)	Needed 35s POST_SLEEP_GAP_S workaround to avoid cuMemMap race	1s, no workaround
Cross-peer swap total	~50s	~3s

3 seconds is the headline number. For a rotation pool where one user request can trigger a cross-peer swap, 50s → 3s is the difference between “annoying” and “invisible.”

What we learned that wasn’t obvious

1. PyTorch’s “private pools” OOM label includes the cumem allocator’s MemPool. Not just cuda graphs. If you’re chasing graph-capture configuration based on this label, you might be looking at the wrong thing.

2. current_platform.is_device_capability_family(120) is the right pattern for SM12x-specific config. If you’re adding consumer-Blackwell adaptations, gate them behind this so non-SM12x users see no change.

3. PR #41834’s perf wins come with memory costs that aren’t called out in the PR description. The 22 GiB non-cumem footprint isn’t documented. If you’re testing on H200 you’d never notice; on consumer Blackwell you’ll hit it immediately.

4. --enforce-eager as a DIAGNOSTIC is more useful than as a deployment posture. It’s the cleanest way to ask “is this OOM coming from graphs?” Even when you don’t want to deploy with it, run one experiment with it to disambiguate.

5. The cumem cycle leak is real but secondary. We chased it for weeks thinking it was the primary blocker. With PR #35489 + PR #34600 + the 0.70 config, we no longer have to alloc-restart for cumem accumulation under our normal rotation load.

What about other attention types

Sleep-mode behavior on consumer Blackwell is attention-type sensitive. What works for one architecture’s KV cache layout and routing table doesn’t necessarily work for another. What we’ve validated on this stack:

Model	Attention	Status
DeepSeek-V4-Flash	sparse-MLA (Triton fallback via PR #41834)	Full sleep/wake at TP=4. Live.
MiMo-V2.5-Flash	dense MLA	Full sleep/wake at TP=4. Live.
Q3-Coder-Next-80B-A3B	hybrid DeltaNet + SWA	/sleep level=2 does not release cleanly on the cu129 image — VRAM stays held. We keep this one always-awake. Tracking vllm#41602.
Single-GPU 7B-class dense	standard MHA / GQA	Sleep/wake works trivially. Sub-second on llama-swap pools. This is the easy case.

If you’re trying sleep-mode on a model with an unusual attention variant (hybrid linear/SWA, RWKV-style, Mamba) on consumer Blackwell, budget extra time. The cumem allocator path is uniform; the per-architecture /sleep + /wake_up release paths are not.

What’s in the repo

vllm-blackwell-sm12x-bundle:

• Dockerfile.builder + Dockerfile.bundle (the two-stage build)
• patches/cumem-fix-stack-pr35489-pr34600.patch (the cherry-pick stack, regenerable)
• nomad-examples/vllm-dsv4-flash.nomad (a working production spec)
• Full README with the gotchas above

Apache-2.0. PRs welcome — especially benchmarks on hardware we haven’t tested.

Acknowledgements

@jasl + @aabbccddwasd for PR #41834, which is the entire SM12x DSv4 enablement. @haosdent for PR #35489, the one-line fix that took us a week to find. The vLLM cumem allocator authors for the sleep/wake_up design that makes 3-second model swap possible at all.
